Trek Checkpoint+ SL 5 2026 - Matte Bronze Age/Dark Web

Trek Bikes

£4,500.00
Price Match Request
Check Availability
XS £4,500.00 Due: December
S £4,500.00 Due: October
M £4,500.00 IN STOCK Dispatch Within 24 Hours
M/L £4,500.00 Supplier Warehouse Dispatch Within 1 Week
L £4,500.00 Supplier Warehouse Dispatch Within 1 Week
XL £4,500.00 Supplier Warehouse Dispatch Within 1 Week
Shipping:
Calculated at Checkout
In Stock
Adding to cart… The item has been added
Pre Order Reserve with £200 Cycle To Work Reservation

Finance Options

Available as a payment option during checkout.

Trek Checkpoint+ SL 5 2026

The Checkpoint+ SL 5 is an electric gravel bike built to take you the distance. You get the smooth and natural-feeling boost of TQ's HPR60 motor to get you through tough climbs and a 360 Wh battery that keeps going on your biggest rides. It comes ready to roll with an OCLV Carbon frame, 12-speed Shimano GRX 1x shifting and endurance geometry to keep you comfortable for the long haul.






Geometry


Frame size letterXSSMMLLXL
Wheel size 700c 700c 700c 700c 700c 700c
A — Seat tube 44.5 48.0 50.5 53.0 55.0 57.5
B — Seat tube angle 74.0° 74.0° 73.3° 73.3° 73.3° 73.5°
Effective seat tube angle 72.7° 73.0° 72.8° 72.8° 72.8° 72.8°
C — Head tube length 8.6 10.6 13.0 15.1 17.1 19.1
D — Head angle 71.0° 71.4° 71.6° 72.0° 72.1° 72.4°
E — Effective top tube 53.6 54.7 56.6 57.8 58.9 60.1
G — Bottom bracket drop 7.6 7.6 7.6 7.6 7.6 7.6
H — Chainstay length 44.0 44.0 44.0 44.0 44.0 44.0
I — Offset 4.9 4.9 4.9 4.9 4.9 4.9
J — Trail 7.1 6.8 6.8 6.4 6.4 6.2
K — Wheelbase 102.3 103.2 104.4 105.2 106.3 107.2
L — Standover 74.6 77.2 79.9 81.3 83.7 86.1
M — Frame reach 38.0 38.6 39.1 39.7 40.2 40.6
N — Frame stack 53.5 55.6 57.9 59.7 62.0 64.0

FAQs

Why choose MTB Monster?


Do you offer 0% finance for the bike?


Do you accept Cycle To Work vouchers? How does it work?


I'm still sorting my payment method, can I reserve a bike?


The bike is not yet in stock, can I pre-order one?


How will the bike be delivered & what are the setup requirements?


What are the delivery options?


Can I collect the bike in the store?


I still have more questions, can I speak to someone?


FRAME:
500 Series OCLV Carbon, TQ drive system, IsoSpeed, hidden mudguard mounts, rack mounts, integrated frame bag mounts, invisible cable routing, flat-mount disc, integrated chainkeeper, UDH, 142x12 mm chamfered thru axle
FRAME MATERIAL:
Carbon
FORK BRAND:
Trek (Rigid)
FORK:
Trek Checkpoint, full carbon, tapered steerer, rack mounts, mudguard mounts, flat-mount disc, 12x100 mm thru axle
FORK TRAVEL:
Rigid Fork
MOTOR:
TQ
MOTOR CONTROLLER:
TQ
DISPLAY:
TQ LED Display with Bluetooth & ANT+ Connectivity
DRIVE UNIT:
TQ HPR (60 Nm)
BATTERY:
360 Wh Battery
RANGE EXTENDER:
TQ HPR Range Extender 160Wh Available for Purchase
CHARGER:
TQ 4A charger
WHEEL SIZE:
700 c
WHEELS:
Bontrager Paradigm Comp 25, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle / Front Skewer: Bontrager Switch chamfered thru axle / Rear Skewer: Bontrager Switch chamfered thru axle, removable lever
TYRES:
Bontrager Girona Pro, Tubeless Ready, GR puncture protection, aramid bead, 60 tpi, 700x42 mm
DROPPER SEATPOST:
No
SEATPOST:
Bontrager carbon, 27.2 mm, 8 mm offset, 330 mm length
SADDLE:
Verse Short Comp, steel rails, 145 mm width
CRANKSET:
Size S, XS: Praxis Alloy, 165 mm length / Size M, ML: Praxis Alloy, 170 mm length / Size XL, L: Praxis Alloy, 172.5 mm length
HANDLEBAR:
Size S, XS: Bontrager Elite Gravel, alloy, 40 cm width / Size M, ML: Bontrager Elite Gravel, alloy, 42 cm width / Size: L Bontrager Elite Gravel, alloy, 44 cm width / Size XL: Bontrager Elite Gravel, alloy, 46 cm width
STEM:
Size XS: Bontrager Elite, 31.8 mm, Blendr / Size XL: Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100mm length-compatible, 7-degree, 70 mm length / Size S, M: Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length / Size ML, L:
TAPE:
Bontrager Supertack Perf tape
SHIFTERS:
Shimano GRX RX820, 12-speed
BRAKE BRAND:
Shimano
HYDRAULIC BRAKES:
Yes
BRAKES:
Shimano GRX RX820, 12-speed
FRONT DERAILLEUR:
N/A
REAR DERAILLEUR:
Shimano GRX RX822, 51T max cog
CHAIN:
Shimano XT M8100, 12-speed
NUMBER OF GEARS:
12 speed
PEDALS:
N/A
FRONT MUDGUARD:
MTB Monster Mudguard
EXTRAS:
N/A
PLEASE NOTE:
Trek reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible p
