| Label | Specification | F-TRICK 26 |
|---|---|---|
| A | Seat tube length | 350 mm |
| B | Top tube length | 550 mm |
| C | Bottom bracket drop | −10 mm |
| D | Bottom bracket height | 285 mm |
| E | Chainstay length | 420 mm |
| F | Seat tube angle | 71° |
| G | Effective seat tube angle | 76° |
| H | Head tube angle | 65.5° |
| I | Fork offset | 41 mm |
| J | Wheelbase | 1050 mm |
| K | Head tube length | 90 mm |
| L | Reach | 377 mm |
| M | Stack | 553 mm |
- FRAME:
- F-Trick 26 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, one piece bolt-on upper link, 12x148mm rear axle, UDH, 73mm BSA bottom bracket, HHG internal cable routing, dedicated 1x drivetrain design.
- FRAME MATERIAL:
- Aluminium
- FORK BRAND:
- X-Fusion
- FORK:
- X-Fusion Slant RC 26, 120mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload
- FORK TRAVEL:
- 120 mm
- REAR SHOCK:
- X-Fusion 02PRO R, 165x42.5mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
- WHEEL SIZE:
- 24"
- WHEELS:
- Rims: MDK-XP1 24 TLR, 25mm internal width, tubeless ready, 32 spokes / Front Hub: DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts / Rear Hub: DA207R 12x148mm, cup & cone ball bearings, IS 6 bolts, HG freehub / Spokes: CN round stainless ste
- TYRES:
- Front Tyre: Maxxis Minion DHF 24x2.4, Tubeless ready, 3C MAXX TERRA, EXO Protection, 60TPI, folding bead / Rear Tyre: Maxxis Minion DHR II 24x2.3, Tubeless ready, EXO Protection, 60TPI, folding bead
- DROPPER SEATPOST:
- Yes
- SEATPOST:
- X-Fusion Manic LC internal, diameter 31.6mm, 1X Remote lever, 100mm
- SADDLE:
- SDG Fly JR
- CRANKSET:
- Prowheel DMJ-CR094S-TT, Direct mount chainring, 150mm
- STEM:
- Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
- GRIPS:
- Onoff Beehive, 1lock-on, 135mm
- SHIFTERS:
- Shimano Deore M6100, Rapid Fire Plus, 12s
- BRAKE BRAND:
- Shimano
- HYDRAULIC BRAKES:
- Yes
- BRAKES:
- Shimano MT501, RT56 180mm IS 6 bolts rotor, resin pads
- REAR DERAILLEUR:
- Shimano Deore M6100, SGS, Shadow+, 12s
- CHAIN:
- Shimano Deore M6100, 12s, Quick-link
- NUMBER OF GEARS:
- 12 Speed
- PEDALS:
- SDG Slater JR
- FRONT MUDGUARD:
- MTB Monster Front Mudguard
- BELL:
- N/A
- EXTRAS:
- N/A
- PLEASE NOTE:
- Mondraker reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing.
