F-PLAY
SO THAT NO ONE IN THE FAMILY SHOULD GO WITHOUT THE EXPERIENCE OF RIDING A PROPER MONDRAKER
Mondraker take their kids bikes very seriously. So seriously that they wanted to create an all-new KIDS range that was so much fun, so capable, so high-tech that it would be hard to tell apart from our adult bikes when out on the trails with your family. That’s what they were going for, and that’s what they've done.
F-PLAY. EBIKES THAT HELP YOU GROW
If you want your little-ones to get better at mountain biking you’ll need a bike that helps them do just that. That’s why Mondraker has completely redesigned their F-Play range, making them unarguably the best two-wheeled investment ever when it comes to smiles per mile. They've gone all-in, leveraging adult-bike tech to design the best kids bikes out there.
Geometry
| Code | Measurement | F-PLAY 26 |
|---|---|---|
| A | Seattube length | 350 mm |
| B | Toptube length | 550 mm |
| C | Bottom bracket drop | -10 mm |
| D | Bottom bracket height | 320 mm |
| E | Chainstay length | 420 mm |
| F | Seat tube angle | 71° |
| G | Effective seattube angle | 76° |
| H | Headtube angle | 67° |
| I | Fork Offset | 39 mm |
| J | Wheelbase | 1104 mm |
| K | Headtube length | 90 mm |
| L | Reach | 415 mm |
| M | Stack | 545 mm |
- FRAME:
- F-Play 26 6061 Alloy Stealth evo, hydroformed tubing, Zero Suspension System, 130mm travel, one piece bolt-on upper link, integrated internal non-removable battery, Tapered head tube, HHG internal cable routing, BSA bottom bracket, 1x drivetrain comp
- FRAME MATERIAL:
- Aluminium
- FORK BRAND:
- X-Fusion
- FORK:
- X-Fusion Slant RC 26, 140mm, air spring, tapered steerer tube, 15x100mm axle, 34mm aluminum stanchions, 41mm offset. Settings: lockout, rebound, air preload
- FORK TRAVEL:
- 140 mm
- REAR SHOCK:
- X-Fusion 02PRO R, 165x45mm. Settings: low-speed rebound, air preload. Trunnion top, 50x8mm bottom bushings
- MOTOR:
- Mahle
- MOTOR CONTROLLER:
- Mahle ONE Head Unit
- DISPLAY:
- Not Included
- DRIVE UNIT:
- Mahle X30
- BATTERY:
- Mahle 250Wh
- RANGE EXTENDER:
- N/A
- CHARGER:
- Mahle
- WHEEL SIZE:
- 26"
- WHEELS:
- Rims: MDK-HP1 26 TLR, 25mm internal width, tubeless ready, 32 spokes / Front Hub: DA210FS02, 15x100mm, cup & cone ball bearings, IS 6 bolts / Rear Hub: Mahle-Ebikemotion X-30, HG freehub
- TYRES:
- Front: Maxxis Minion DHF 26x2.5, Tubeless ready, 3C MAXX TERRA, EXO Protection, 60TPI, folding bead / Rear: Maxxis Minion DHR II 26x2.4, Tubeless ready, EXO Protection, 60TPI, folding bead
- DROPPER SEATPOST:
- Yes
- SEATPOST:
- X-Fusion Manic LC internal, diameter 31.6mm, 1X Remote lever, 125mm
- SADDLE:
- SDG Fly JR
- CRANKSET:
- Prowheel DMJ-CR094S-TT, Direct mount chainring, 155mm
- STEM:
- Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore
- GRIPS:
- Onoff Beehive, 1lock-on, 135mm
- SHIFTERS:
- Shimano Deore M6100, Rapid Fire Plus, 12s
- BRAKE BRAND:
- Shimano
- HYDRAULIC BRAKES:
- Yes
- BRAKES:
- Shimano MT520, 4-piston caliper, RT56 180mm IS 6 bolts rotor, resin pads
- REAR DERAILLEUR:
- Shimano Deore M6100, SGS, Shadow+, 12s
- CHAIN:
- Shimano Deore M6100, 12s, Quick-link
- NUMBER OF GEARS:
- 12 Speed
- PEDALS:
- SDG Slater JR
- FRONT MUDGUARD:
- MTB Monster Mudguard
- BELL:
- N/A
- EXTRAS:
- N/A
- PLEASE NOTE:
- Mondraker reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing.
