San Quentin 24"
The Marin San Quentin 24”, just like the big kid’s version, shreds the boundaries of the mountain bike genres - doing it all with a huge splash of big air, speed and style.
The San Quentin 24” will feel just like a ‘grown up’ mountain bike to your little ripper, built with a stout Series 2 aluminum frame, 24” wheels, an RockShox suspension fork, 9-speed microSHIFT drivetrain and kid’s specific hydraulic disc brakes.
Technology
Dirt jump inspired frame style: Taking cues from the Alcatraz, as well as the full-size San Quentin lineup, the San Quentin 24” and 20” proved all the benefits of DJ style, with massive standover, slick frame tubes, and a hot paint job.Modern Trail Geometry: A slack headtube angle paired with a steep seat tube angle creates a ride that will fly uphill, yet descend like it’s on rails. The balanced rider position is puts the rider weight between the wheels for steady climbing and handling on flats, while the slack front end helps to add higher speed stability through turns and rough patches.
1x Wide-Range Drivetrain: Modern 1x drivetrains, just like the larger San Quentins, give the rider the benefits of shifting simplicity and chain retention.
Geometry
| A - STACK | 541 |
| B - REACH | 345 |
| C - HEAD TUBE ANGLE | 65 ° |
| D - HEAD TUBE LENGTH | 90 |
| E - SEAT TUBE ANGLE | 75 ° |
| F - SEAT TUBE LENGTH | 331 |
| G - TOP TUBE EFFECTIVE | 490 |
| H - BB HEIGHT | 292 |
| I - BB DROP | 30 |
| J - CHAIN STAY | 340 |
| K - WHEEL BASE | 1009 |
| L - STAND OVER HEIGHT | 588 |
| M - FORK OFFSET | 42 |
| SEATPOST DIAMETER | 30.9 |
| HANDLEBAR WIDTH | 590 |
| STEM LENGTH | 35 |
| CRANK LENGTH | 152 |
- FRAME:
- Series 2 6061 Aluminum, 24” Wheels, Disc Specific, 135mm Dropouts
- FRAME MATERIAL:
- Aluminium
- FORK BRAND:
- Manitou
- FORK:
- Manitou Junit Sport, 24", 100mm Travel, Air Sprung, Adjustable Rebound, Tapered Steerer, 15x110mm Axle
- FORK TRAVEL:
- 100 mm
- WHEEL SIZE:
- 24"
- WHEELS:
- Rims: Marin, Double Wall Alloy, 27mm Internal / Hubs: Forged Aluminum, 32H, Disc Specific
- TYRES:
- Vee Tire Co. Crown Gem, 24”x2.6”, Wire Bead
- DROPPER SEATPOST:
- No
- SEATPOST:
- Integrated With Saddle
- SADDLE:
- Marin One-Piece Saddle/Post Combo, 27.2mm Alloy Post
- CRANKSET:
- Forged Alloy, Narrow Wide 30T, 140mm
- STEM:
- Marin Alloy, 40mm
- GRIPS:
- Marin MTB, Small Diameter
- SHIFTERS:
- Shimano CUES, SL-U4000, 9-speed
- BRAKE BRAND:
- Shimano
- HYDRAULIC BRAKES:
- Yes
- BRAKES:
- Shimano MT200, Hydraulic, 160mm Rotor
- REAR DERAILLEUR:
- Shimano CUES, RD-U4000, 9-speed
- CHAIN:
- KMC X9
- NUMBER OF GEARS:
- 9 Speed
- PEDALS:
- Kids Specific Nylon Pedal
- FRONT MUDGUARD:
- MTB Monster Mudguard
- BELL:
- N/A
- EXTRAS:
- N/A
- PLEASE NOTE:
- Marin reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materialsMarin reserve the right to make changes to the pr
