Cannondale Habit LT 2 - The Thrill Seeker
The Habit LT 2 2025 is a progressive trail mountain bike, precisely tuned for controlled chaos. This full suspension MTB is down for the ups but lives to get down, eagerly seeking out challenging terrain and built for the rough and rowdy adventures you crave. Its slacker 64.7° head tube angle and steep 77° seat tube angle put you in an optimal position to shred descents and control your bike with confidence. Plus, thanks to its Proportional Response Design, the geometry, suspension layout and even the chainstay length are all uniquely customized for each size, guaranteeing optimal performance no matter your fit.
Highlights
Shimano Deore Hydraulic Brakes: With Powerful brakes this MTB ensures immense stopping power when you need it most.
Geometry

SM | MD | LG | XL | |
---|---|---|---|---|
Wheel Size | 29" | 29" | 29" | 29" |
A Seat Tube Length (cm) | 38.0 | 40.0 | 44.5 | 50.0 |
B Top Tube Horizontal (cm) | 56.3 | 59.0 | 61.7 | 65.4 |
C Top Tube Actual (CM) | 53.1 | 55.4 | 58 | 61.5 |
D Head Tube Angle | 64.7° | 64.7° | 64.7° | 64.7° |
E1 Seat Tube Angle Actual | 70.6° | 70.6° | 71.9° | 72.1° |
E Seat Tube Angle Effective | 77.1° | 77.1° | 77.1° | 77.1° |
F Standover (cm) | 74.3 | 74.8 | 75.7 | 76.7 |
G Head Tube Length (cm) | 11.0 | 12.0 | 13.0 | 14.0 |
H Wheelbase (cm) | 117.4 | 120.4 | 124.0 | 128.0 |
I Front Center (cm) | 74.2 | 77.1 | 80.7 | 84.7 |
J Chain Stay Length (cm) | 43.5 | 43.5 | 44.5 | 44.5 |
K Bottom Bracket Drop (cm) | 3.4 | 3.4 | 3.4 | 3.4 |
L Bottom Bracket Height (cm) | 34.4 | 34.4 | 34.4 | 34.4 |
M Fork Rake (cm) | 4.2 | 4.2 | 4.2 | 4.2 |
N Trail (cm) | 13.0 | 13.0 | 13.0 | 13.0 |
O Stack (cm) | 62.6 | 63.5 | 64.4 | 65.3 |
P Reach (cm) | 42.5 | 45.0 | 47.5 | 51.0 |
FAQs: Cannondale Habit LT 2 2025
Basics
What size bike do I need?
What is Invisiframe and is it worth fitting it to the Habit?
What is tubeless setup and can the Habit be set up tubeless?
What equipment & info will the bike arrive with?
Is it possible to see the Habit in your showroom & is it possible to have a test ride or demo it?
What type of bike is the Habit and what is it designed for?
What type of terrain is the Habit ideally suited towards? Singletrack trails with some technical descents. Up to and including red routes at trail centres.
How should you clean & maintain the Habit LT 2?
I'm new to riding, what essential bits of kit do I need to get going?
Where can I ride the Habit LT 2?
Technical
Where can I find all of the major components that come on the bike?
Can you fit a water bottle on the bike?
What warranty comes on the Habit LT 2?
Does the Habit LT 2 come with pedals?
Can I get hold of spare / replacement parts easily for the Habit LT 2?
Can I add upgrades to the bike?
Purchasing
Why choose MTB Monster?
Do you offer 0% finance for the Habit LT 2?
Do you accept Cycle To Work vouchers? How does it work?
I'm still sorting my payment method, can I reserve a bike?
The bike is not yet in stock, can I pre-order one?
How will the bike be delivered & what are the setup requirements?
What are the delivery options?
Can I collect the bike in the store?
I still have more questions, can I speak to someone?
- FRAME:
- Habit SmartForm C1 Alloy, 140mm travel, Proportional Response Suspension and Geo, 55mm chainline, ISCG05, BSA threaded BB, post mount brake, tapered headtube, DirectLine internal cable routing, UDH hanger
- FRAME MATERIAL:
- Aluminium
- FORK BRAND:
- RockShox
- FORK:
- RockShox Lyrik, 150mm, DebonAir, 15x110mm thru-axle, tapered steered, 42mm offset
- FORK TRAVEL:
- 150 mm
- WHEEL SIZE:
- 29
- WHEELS:
- Rims: WTB ST i30 TCS, 32h, tubeless ready / Hubs: (F) Formula, 15x110mm thru-axle / (R) Shimano TC500, 12x148mm thru-axle
- TYRES:
- (F) Maxxis Minion DHF, 29x2.5" (27.5x2.5" - XS), 3C, EXO+, tubeless ready / (R) Maxxis Dissector, 29x2.4" (27.5x2.4" - XS), 3C, EXO+, tubeless ready
- DROPPER SEATPOST:
- Yes
- SEATPOST:
- Cannondale DownLow Dropper, internal routing, 31.6, 125mm (XS-S), 150mm (M), 170mm (L-XL)
- SADDLE:
- Cannondale Scoop Shallow Sport, steel rails
- CRANKSET:
- Shimano, FC-6120, 30T, 55mm chainline
- STEM:
- Cannondale 3, 6061 Alloy, 31.8, 0°
- GRIPS:
- Cannondale TrailShroom
- SHIFTERS:
- Shimano SLX, 12-speed
- BRAKE BRAND:
- Shimano
- HYDRAULIC BRAKES:
- Yes
- BRAKES:
- Shimano Deore M6120 4-piston disc, 203/180mm RT64 rotors
- REAR DERAILLEUR:
- Shimano XT
- CHAIN:
- Shimano SLX, 12-speed
- NUMBER OF GEARS:
- 12 Speed
- PEDALS:
- Available for Purchase
- FRONT MUDGUARD:
- MTB Monster Mudguard
- EXTRAS:
- N/A
- TYPE OF BIKE:
- Trail
- DESIGNED FOR:
- Exploring new trails or going on longer rides where you encounter varied terrain. More relaxed geometry than a Cross Country bike and an excellent balance of climbing ability and downhill capability making it a great all-rounder
- IDEAL TERRAIN:
- Singletrack trails with some technical descents. Up to and including red routes at trail centres.
- PLEASE NOTE:
- Cannondale reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.
